Digital AC Power Meter 2503
Yokogawa Electric Co., YEW; Musashino-shi, Tokyo
- Country
- Japan
- Manufacturer / Brand
- Yokogawa Electric Co., YEW; Musashino-shi, Tokyo
- Year
- 1970–1985 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 154676
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Digital AC Power Meter 2503 - Yokogawa Electric Co., YEW;
- Shape
- Rack
- Dimensions (WHD)
- 439 x 149 x 365 mm / 17.3 x 5.9 x 14.4 inch
- Notes
- 3 Phasen Power Meter auch für 1 Phasen Messung geeignet
Messbereich:600mW-36KW
Spannung:3V-600V max 1000V in 6 Stufen
Strom:0,1A-30A in 7 Stufen
Input R:10KOhm/V
Digitalanzeige 5 stellig.
- Net weight (2.2 lb = 1 kg)
- 16 kg / 35 lb 3.9 oz (35.242 lb)
- Author
- Model page created by Rudolf Osterkamp. See "Data change" for further contributors.
