Analog Multimeter YF-370

• Country
• Taiwan (Republic of China)

• Manufacturer / Brand
• Yu Fong Electric Co. Ltd., YFE; Taipei

• Year
• 1980 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 316885

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / AA: 2 x 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• from Radiomuseum.org
• Model: Analog Multimeter YF-370 - Yu Fong Electric Co. Ltd., YFE

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Notes

• Yu Fong Electronic Co. Ltd. Analog Multimeter YF-370

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.

• Other Models

• Here you find 24 models, 20 with images and 14 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
