UHF-Gitterwand-Antenne AS23
Zehnder GmbH; Tennenbronn/Schwarzwald
- Country
- Germany
- Manufacturer / Brand
- Zehnder GmbH; Tennenbronn/Schwarzwald
- Year
- 1965–1975 ??
- Category
- Antenna (Aerial) or Coupler
- Radiomuseum.org ID
- 324794
gemeinsame Schachtel
Einheitsverpackung
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- No Power needed
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: UHF-Gitterwand-Antenne AS23 - Zehnder GmbH; Tennenbronn/
- Shape
- Miscellaneous shapes - described under notes.
- Notes
-
Die Zehnder UHF-Gitterwand-Antenne AS23 ist für den Empfang der TV-Kanäle 21-60 entspr. 470-790 MHz im Band IV und V vorgesehen.
- Spannungsgewinn 10,5-12,5 dB
- Vor-Rückverhältnis 23-26 dB.
Mastmontage, wahlweise für 240/300 Ω oder 60/75 Ω Kabelanschluss vorgesehen.
- Author
- Model page created by Manfred Rathgeb. See "Data change" for further contributors.
