• Country
• Spain

• Manufacturer / Brand
• Zend (Marca), Ibero-Shon; Barcelona

• Year
• 1993 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 326156

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• A66EAK51X

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Monitor CCTV Z-MMF28 - Zend Marca, Ibero-Shon;

• Shape
• Tablemodel, with any shape - general.

• Notes

• Zend, marca de Ibero-Shon, S.A., monitor CCTV Z-MMF28

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
