• Country
• United States of America (USA)

• Manufacturer / Brand
• Zenith Radio Corp.; Chicago, IL

• Year
• 1937/1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 67324

• • alternative name: Chicago Radio Lab

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• 6K7G 6L7G 6J5G 6K7G 6T5 6H6G 6J5G 6J5G 6J5G 6V6G 6V6G 5Y4G

• Main principle
• Superhet with RF-stage; ZF/IF 456 kHz

• Wave bands
• Broadcast, Short Wave(s) and Police.

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm

• Power out
• 15 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 12-S-232 "Waltons" Ch=1204 - Zenith Radio Corp.; Chicago,

• Shape
• Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.

• Dimensions (WHD)
• 16.9 x 23.8 x 12.4 inch / 429 x 605 x 315 mm

• Notes

• The popular set from the TV series "The Waltons".

  The cabinet is similar for the following "Walton" models:
  12-S-232
    9-S-232
    9-S-232AT
    8-A-232
    7-S-232
    7-S-232T
    7-J-232
    7-J-232T
  They are looking all the same. That's why all of them are called "Waltons" although only one thereof was in the play.


   The schematic diagram got corrections (red). These lines are already missing in the Zenith drawing as well as in Riders and in Beitman.

• Price in first year of sale
• 100.00 $

• External source of data
• Ernst Erb

• Source of data
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Circuit diagram reference
• Rider's Perpetual, Volume 8 = 1937 and before

• Mentioned in
• Collector's Guide to Antique Radios 4. Edition

• Literature/Schematics (1)
• Zenith Radio The Glory Years 1936-1945

• Literature/Schematics (2)
• Table Top Radios Vol. 1 Stein 98 (page 170.)

• Literature/Schematics (3)
• Cathedral & Tombstone Radios (page 283.)

• Literature/Schematics (4)
• Zenith Radio The Glory Years 1936-1945 (p.1938.1 and p.82)
