28T925EU "Biltmore" Ch= 28F22
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1949
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 246539
-
- alternative name: Chicago Radio Lab
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 117 V Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: 28T925EU "Biltmore" Ch= 28F22 - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel, low profile (big size).
- Notes
-
TV with 10" Bullseye Screen, US VHF Tuner, Channels 2 through 13. Wood blonde.
- Mentioned in
- Riders 3-1 Zenith TV3
- Author
- Model page created by Hans Amberger. See "Data change" for further contributors.
