5D012TZ Consoltone Ch= 5C60TZ brown
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1947 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 241743
-
- alternative name: Chicago Radio Lab
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- 100-96
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- AC/DC-set / 115; 230 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.25 inch = 10.8 cm
- Power out
- 3 W (unknown quality)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 5D012TZ Consoltone Ch= 5C60TZ [brown] - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 315 x 165 x 138 mm / 12.4 x 6.5 x 5.4 inch
- Notes
-
Tuning ranges:
BC 545 - 1520 kc,
SW1 2.35 - 7.1 Mc,
SW2 6.9 - 22.0 Mc.
Dial lamp: #47 (6,3V/0,15A).
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
