• Country
• United States of America (USA)

• Manufacturer / Brand
• Zenith Radio Corp.; Chicago, IL

• Year
• 1942

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 74159

• • alternative name: Chicago Radio Lab

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / =6 Volt

• from Radiomuseum.org
• Model: 6MN695 Nash AC-6002 6-MN-695 Ch=6B22 - Zenith Radio Corp.; Chicago,

• Notes
• listed only in Lit.

• Source of data
• Zenith Radio The Glory Years 1936-1945

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
