• Country
• United States of America (USA)

• Manufacturer / Brand
• Zenith Radio Corp.; Chicago, IL

• Year
• 1963 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 337666

• • alternative name: Chicago Radio Lab

• Number of Tubes
• 12

• Valves / Tubes
• 6JK8 6BA6 6BE6 6BA8 6BA6 6AU6A 6BC7 6BN8 6EA8 12AX7A 7695 7695

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-120 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: AM-FM-Turntable Console Ch= 9H21LZ1/Z2, 3K01/01Z/01Z1/02 - Zenith Radio Corp.; Chicago,

• Shape
• Console, Lowboy (legs < 50 %).

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 650, Folder 10, August 1963)

• Author
• Model page created by Joe Holland. See "Data change" for further contributors.
