C835W "The Super Symphonaire" Ch= 8C01
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1959 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 146965
-
- alternative name: Chicago Radio Lab
Zenith Photofact Folder
Picture from 1960 Zenith sales brochure
RECONSTRUCTED LABEL
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- AC/DC-set / 110 - 120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: C835W "The Super Symphonaire" Ch= 8C01 - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 15.625 x 10.375 x 8 inch / 397 x 264 x 203 mm
- Notes
-
Sams photofact set 485 folder 18 date 5-60 features the Zenith models C835E, C835H, C835R, C835W with chassis 8C01 and the models C845L, C845M, C845W, C845Y with chassis 8C02 as the same schematic.
The various letter designations between models refer to cabinet color. The available cabinet colors are shown on the sales brochure photo, however, the specific color vs. letter designation is not known.
