G2952-ROX Ch= 29G20
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1950 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 252705
-
- alternative name: Chicago Radio Lab
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 29
- Valves / Tubes
- 6BJ6 or 6AG5 6AG5 6J6 6AU6 6AU6 6AH6 12AT7 6AC7 12AT7 or 6SL7GT 6SL7GT 6AU6 6AU6 6AU6 6T8 6V6GT 6AU6 or 6SN7GT 6SH7 or 12AT7 6SN7GT 6V6GT 6AL5 6AC7 6K6GT 6BG6G 6BG6G 5V4G 1B3GT 5U4G 5U4G 16EP4 or 12KP4 or 12LP4
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.5 inch = 24.1 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: G2952-ROX Ch= 29G20 - Zenith Radio Corp.; Chicago,
- Shape
- Console with any shape - in general
- Notes
-
Television Receiver
Channels 2 thru 13
- Mentioned in
- Photofact Folder, Howard W. SAMS (Vol.10/50 Date 5-50 95-8 Set 95 Folder 8)
- Author
- Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.
