G516 Ch= 5G03
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 68187
-
- alternative name: Chicago Radio Lab
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Bakelite case
- from Radiomuseum.org
- Model: G516 Ch= 5G03 - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Dimensions (WHD)
- 290 x 150 x 135 mm / 11.4 x 5.9 x 5.3 inch
- Notes
- Bunis 4th Ed. lists erroneously the chassis Nr 5G03 as a model.
- Net weight (2.2 lb = 1 kg)
- 2.3 kg / 5 lb 1.1 oz (5.066 lb)
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 21, Copyright 1950
- Mentioned in
- Collector's Guide to Antique Radios 4. Edition
- Literature/Schematics (1)
- Table Top Radios Vol. 1 Stein 98 (page 175.)
- Literature/Schematics (2)
- Machine Age to Jet Age II (page 327.)
- Literature/Schematics (3)
- Photofact Folder, Howard W. SAMS (Set 109, Folder 15 (109-15), October 1950)
- Literature/Schematics (4)
- Zenith brochure
- Other Models
-
Here you find 4505 models, 4101 with images and 3631 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Zenith Radio Corp.; Chicago, IL
Collections
The model G516 is part of the collections of the following members.
Forum contributions about this model: Zenith Radio Corp.;: G516 Ch= 5G03
Threads: 1 | Posts: 1
The Rider schematic 21-4 shows a negative 1.4V cathode bias voltage, on pin 7 of the I.F. amplifier tube (12BA6). The correct polarity should be positive.
Thomas Cowell, 04.Feb.22
