• Country
• United States of America (USA)

• Manufacturer / Brand
• Zenith Radio Corp.; Chicago, IL

• Year
• 1967–1969 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 169707

• • alternative name: Chicago Radio Lab

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 12

• Valves / Tubes
• 3DG4 6GH8 6DQ6B 6CQ4 1J3 6EA7 6HS8 6AQ5 6BN6 6GN8 6EJ7 6EH7 6EH7 23ANP4

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known.

• Material
• Wooden case

• from Radiomuseum.org
• Model: H2717 - Zenith Radio Corp.; Chicago,

• Shape
• Tablemodel, with any shape - general.

• Notes
• Picture Tube 23ANP4, 23" INCH. Bands: VHF/UHF.

• Literature/Schematics (1)
• Corriente Alterna, Suplemento de Circuitos

• Author
• Model page created by Carlos A. Pieroni-García. See "Data change" for further contributors.
