H664 Ch= 6H02
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1951 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 68220
-
- alternative name: Chicago Radio Lab
Beitman
Zenith Cobra-Matic H 664
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 inch = 19.1 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: H664 Ch= 6H02 - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Zenith model H664 is an AC operated combination phono-radio, superheterodyne receiver with loop antenna.
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 22, covering 1951
- Mentioned in
- Collector's Guide to Antique Radios 4. Edition
- Literature/Schematics (1)
- Beitman Radio Diagrams, Vol. 11, 1951
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 149, folder 15, dated 11-51)
- Other Models
-
Here you find 4505 models, 4101 with images and 3631 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Zenith Radio Corp.; Chicago, IL
Collections
The model H664 is part of the collections of the following members.
Forum contributions about this model: Zenith Radio Corp.;: H664 Ch= 6H02
Threads: 2 | Posts: 6
I'm working on a restoration of a Zenith tabletop radio/turntable that I bought at the closing of an electronics store. After doing a recap of the most obvious capacitors, I tested the voltages of the tubes according to the scematics and all of the voltages came in almost right on with two exceptions:
1. 6AQ6 - Pin 7 should be 48V and it came in at 30V. I bought a new tube and the voltage measured 37V, an improvement, but clearly something still wrong.
2. I was not able to get any reading out of the Phono Pre-Amp (12J5) even after buying a replacement bulb. Of course, I have the radio part of the device out of the shell and the turntable is not connected so that may have something to do with this. Right or wrong?
3. I am unable to get a signal on the radio, just some static and a few spots where it perks up, but no meaningful sound. I don't think that there's an antenna connected so would that be the reason for this or is there a problem elsewhere?
I'm looking for any direction to help with these items.
thanks you in advance!
craig.
Craig Vodnik, 06.Jan.13
Does anyone know the specifications (or can read the schematics) for the dial bulb of this model? I have the burned out one on hand, but it has no specs written on it and the parts list in the schematics only calls it PL-1. It's a bayonet style.
Thanks!
craig.
Craig Vodnik, 31.Dec.12
