H-723G Ch= 7H04

Zenith Radio Corp.; Chicago, IL

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Zenith Radio Corp.; Chicago, IL

Year
1962 ?

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
138181

- alternative name: Chicago Radio Lab

Schematics

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506059) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506060) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506061) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506062) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506063) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506064) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506065) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 506066) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (3)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 2154859) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (2)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 2154860) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (2)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 2154861) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (2)

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 570375) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (2)
Zenith_H-723-G

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 1223429) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (2)
Ebay Seller diogenes425 Item 251045499992

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 1223430) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (2)
Ebay Seller diogenes425 Item 251045499992

H-723G Ch= 7H04; Zenith Radio Corp.; (ID = 2802153) Radio — Zenith Radio Corp.; H-723G Ch= 7H04 (1)
RECONSTRUCTED LABEL

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
7

Valves / Tubes
12DT8 12BE6 12BA6 12BA6 12AU6 19T8 35C5

Main principle
Superhet with RF-stage; ZF/IF 455/10700 kHz; 2 AF stage(s)

Tuned circuits
6 AM circuit(s) 10 FM circuit(s)

Wave bands
Broadcast (BC) and FM or UHF.

Power type and voltage
AC/DC-set / 110 - 120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: H-723G Ch= 7H04 - Zenith Radio Corp.; Chicago,

Shape
Tablemodel, low profile (big size).

Notes
Selenium Rectifier
4" x 6" PM elliptical speaker.
The Zenith Modell H-723G is an AC/DC Operated 7 Tube AM-FM Receiver.

Literature/Schematics (1)
Photofact Folder, Howard W. SAMS (Date 10-62, Set 599, Folder 12)

Author
Model page created by Egon Penker. See "Data change" for further contributors.
