M722C Ch= 6M06
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1964 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 87279
-
- alternative name: Chicago Radio Lab
Sams Photofact Folders reference picture
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 10700 kHz; 2 AF stage(s)
- Tuned circuits
- 8 FM circuit(s)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: M722C Ch= 6M06 - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 12.25 x 6.5 x 6.25 inch / 311 x 165 x 159 mm
- Notes
- Selenium Rectifier
4" x 6" PM elliptical speaker.
The Zenith Modell M722C is a 6 Tube FM Receiver.
- Net weight (2.2 lb = 1 kg)
- 4 lb 14 oz (4.875 lb) / 2.213 kg
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 25, 1965
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 3-65, Set 746, Folder 9)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
