R514V (the Owl) Ch= 5L06
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1955 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 314957
-
- alternative name: Chicago Radio Lab
Picture from Hans Amberger.
Picture from Hans Amberger.
Picture from Hans Amberger.
Picture from Hans Amberger.
Picture from Hans Amberger.
RECONSTRUCTED LABEL x
RECONSTRUCTED LABEL x
- Number of Tubes
- 5
- Main principle
- ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: R514V Ch= 5L06 - Zenith Radio Corp.; Chicago,
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Dimensions (WHD)
- 13.25 x 5.375 x 6 inch / 337 x 137 x 152 mm
- Notes
-
The R514 series of "Owl" clock radios has only one knob on the clock and has the same chassis as the L515 and R515 series.
The following models are identical except for cabinet color.
Model Number Cabinet Color R514F Green R514R Walnut R514V Red (coral) R514W White (ivory)
- Net weight (2.2 lb = 1 kg)
- 4 lb 13 oz (4.813 lb) / 2.185 kg
- Price in first year of sale
- 32.95 USD
