ZP2 Ch= 1L20
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1963 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 87122
-
- alternative name: Chicago Radio Lab
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 25C5
- Main principle
- Audio-Amplification; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: ZP2 Ch= 1L20 - Zenith Radio Corp.; Chicago,
- Notes
- Diode Rectifier.
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 24, 1964
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
