Royal 880 The Vocalaire Ch=9KT40Z6
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 74005
-
- alternative name: Chicago Radio Lab
- Number of Transistors
- 9
- Semiconductors
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / 6x1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Power out
- 0.45 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Royal 880 The Vocalaire Ch=9KT40Z6 - Zenith Radio Corp.; Chicago,
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
- Zeniths first small AM/FM Transistor Radio; available in tan or ebony color; There is also a similar model but with chassis 9KT42Z6.
- Price in first year of sale
- 90.00 $
- Mentioned in
- Zenith Transistor Radios
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
