- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1939 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 73097
-
- alternative name: Chicago Radio Lab
Beitman
Image copy from Zenith folder
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Number of Transistors
- Semiconductors
- 100-76
- Main principle
- Audio-Amplification
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- - For headphones or amp.
- from Radiomuseum.org
- Model: S-7002 - Zenith Radio Corp.; Chicago,
- Notes
-
Wireless Record Player.
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 2, 1939
- Author
- Model page created by Walter Wiesmüller † May 2012. See "Data change" for further contributors.
- Other Models
-
Here you find 4496 models, 4101 with images and 3615 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Zenith Radio Corp.; Chicago, IL
