Stereo Receiver MC7051

Zenith Radio Corp.; Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1980/1981 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 324372
    • alternative name: Chicago Radio Lab

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (undistorted)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Stereo Receiver MC7051 - Zenith Radio Corp.; Chicago,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 490 x 150 x 380 mm / 19.3 x 5.9 x 15 inch
  • Notes

  • This hi-fi stereo receiver has an FM/MW tuner and an amplifier output power of 2 x 40 W into 8 ohms.  There are 2 phono inputs, 2 tape inputs, an aux. input and an input jack for a microphone.  There are 300 ohm balanced and 75 ohm unbalanced connections for FM antennae and a ferrite loopstick AM antenna.  Total Harmonic Distortion is 0.05%.

    Made in Korea

  • Net weight (2.2 lb = 1 kg)
  • 13.6 kg / 29 lb 15.3 oz (29.956 lb)
  • Author
  • Model page created by George Papaiz. See "Data change" for further contributors.
