X2264EQU Ch= 19X22QU

Zenith Radio Corp.; Chicago, IL

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Zenith Radio Corp.; Chicago, IL

Year
1956 ?

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
298673

- alternative name: Chicago Radio Lab

Schematics

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225217) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225218) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225219) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225220) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225221) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225222) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225223) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225224) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225225) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225226) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225227) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225228) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225229) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225230) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225231) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225232) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2225250) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (3)

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2342449) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (2)
Copy from Ad.

X2264EQU Ch= 19X22QU; Zenith Radio Corp.; (ID = 2237747) Television — Zenith Radio Corp.; X2264EQU Ch= 19X22QU (2)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
20

Valves / Tubes
6BK7A 6U8 6AF4A 6CB6 6CB6 6CB6 12BY7 6AU6 6BN6 6AQ5 12AX7 6BE6 12B4 or 12B4A 6CN7 6SN7GT 6BQ6GT or 6BQ6GA or 6CU6 1B3GT 6AX4GT 5U4GA or 5U4G 21ALP4A

Main principle
Superhet with RF-stage

Wave bands
Wave Bands given in the notes.

Power type and voltage
Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

from Radiomuseum.org
Model: X2264EQU Ch= 19X22QU - Zenith Radio Corp.; Chicago,

Notes
The Zenith model X2264EQU is a 21" b/w TV with US standard VHF Tuner channels 2thrue 13,14 thru 83 UHF.Equipped with VHF-tuner S-23113, UHF-tuner S-12115, chassis 12X22QU and picture tube 21ALP4A
