Y1816CU Ch= 16Y20U

Zenith Radio Corp.; Chicago, IL

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Zenith Radio Corp.; Chicago, IL

Year
1955/1956

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
277118

- alternative name: Chicago Radio Lab

Schematics

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933477) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933478) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933479) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933480) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933481) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933482) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933483) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933484) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933485) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933486) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933487) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933488) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933489) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933490) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933491) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933492) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933493) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933494) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933495) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933496) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933497) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933498) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933499) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933500) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933501) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933502) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933503) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933504) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933505) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1933506) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (3)

Y1816CU Ch= 16Y20U; Zenith Radio Corp.; (ID = 1990082) Television — Zenith Radio Corp.; Y1816CU Ch= 16Y20U (2)
Copy from Ebay seller 610cl

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
17

Valves / Tubes
5BK7A 2AF4A 5U8 3CB6 3CB6 3CB6 6AU8 3BN6 5AQ5 3BU8 6CM7 6CN7 6CG7 12DQ6 1B3GT 12AX4GTA 17AVP4 or 17AVP4A

Main principle
Superhet with RF-stage

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Alternating Current supply (AC) / 60 cycles, 110-120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

Power out
1.3 W (1.6 W max.)

from Radiomuseum.org
Model: Y1816CU Ch= 16Y20U - Zenith Radio Corp.; Chicago,

Notes
The Zenith Y1816CU is a 17" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 16Y20U, VHF tuner S-24383, UHF tuner S-22530 and picture tube 17AVP4 or 17AVP4A.
