Y2636EZ Ch= 17X23

Zenith Radio Corp.; Chicago, IL

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Zenith Radio Corp.; Chicago, IL

Year
1956 ?

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
282785

- alternative name: Chicago Radio Lab

Schematics

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004494) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004495) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004496) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004497) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004498) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004499) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004500) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004501) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004502) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004503) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004504) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004505) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004506) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004507) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004508) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004509) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004510) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2004511) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (3)

Y2636EZ Ch= 17X23; Zenith Radio Corp.; (ID = 2100664) Television — Zenith Radio Corp.; Y2636EZ Ch= 17X23 (2)
USA_Zenith_model Y2636 copy from folder.

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
17

Valves / Tubes
6BK7A 6U8 6CB6 6CB6 6AU8 6AU8 6BN6 6AQ5 6BY6 12B4A 6AL5 6SN7GTB 6BQ6GA 6AX4GT 1B3GT 5U4GA 24DP4A

Main principle
Superhet with RF-stage

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Alternating Current supply (AC) / 60 cycle 110-120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

Material
Wooden case

from Radiomuseum.org
Model: Y2636EZ Ch= 17X23 - Zenith Radio Corp.; Chicago,

Shape
Console, Lowboy (legs < 50 %).

Notes
The ZENITH model Y2636EZ is a 24" b/w TV with US standard VHF Tuner channels 2 thru 13, equipped with VHF-tuner S-23212, chassis 17X23 and picture tube 24DP4A.

Literature/Schematics (1)
Photofact Folder, Howard W. SAMS (Set 338 Folder 12 dated 11-56)

Author
Model page created by Dirk Taekels. See "Data change" for further contributors.
