Z2220RDU Ch= 17Y20U

Zenith Radio Corp.; Chicago, IL

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Zenith Radio Corp.; Chicago, IL

Year
1955/1956

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
272024

- alternative name: Chicago Radio Lab

Schematics

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877730) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877731) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877732) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877733) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877734) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877735) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877736) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877737) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877738) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877739) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877740) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877741) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877742) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877743) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877744) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877745) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877746) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877747) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877748) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877749) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877750) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877751) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877752) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877753) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877754) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877755) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877756) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877757) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877758) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1877759) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (3)

Z2220RDU Ch= 17Y20U; Zenith Radio Corp.; (ID = 1978562) Television — Zenith Radio Corp.; Z2220RDU Ch= 17Y20U (2)
Copy from Zenith folder.

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
18

Valves / Tubes
6BK7A 6U8 6AF4 3CB6 3CB6 3CB6 6AU8 3BN6 6AQ5 6BU8 6CM7 6CN7 6CG7 6DQ6 1B3GT 6AX4GT or 6AX4GTA 5U4GA or 5U4GB 21ALP4 or 21ALP4A

Main principle
Superhet with RF-stage

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Alternating Current supply (AC) / 60 cycles, 110-120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

Power out
1.3 W (1.6 W max.)

from Radiomuseum.org
Model: Z2220RDU Ch= 17Y20U - Zenith Radio Corp.; Chicago,

Notes
The Zenith Z2220RDU is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 17Y20U, VHF tuner S-24393, UHF tuner S-22790 and picture tube 21ALP4 or 21ALP4A.

Literature/Schematics (1)
Photofact Folder, Howard W. SAMS (Set 335, folder 19 dated 10-56)

Literature/Schematics (2)
Zenith Service Manual - 1957 Television Receivers TV-17

Literature/Schematics (3)
Zenith Service Manual - 1956 Television Receivers TV-16

Author
Model page created by John Kusching. See "Data change" for further contributors.
