- Country
- Italy
- Manufacturer / Brand
- Zetagi S.p.A.; Concorezzo, Milano
- Year
- 1998 ??
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 287339
-
- Brand: ZG
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Radio Frequency Amplification only
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage and/or dry batteries / 12 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: B153 - Zetagi S.p.A.; Concorezzo,
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 118 x 42 x 100 mm / 4.6 x 1.7 x 3.9 inch
- Notes
-
ZETAGI mod. B 153
Frequency 26-30 MHz frequency, power supply 11-14 volts, current consumption 8/10 amp, input power 0.5 / 5 Watt AM, 1-10 Watts SSB, output power 100 Watts AM, 200 Watts SSB, electronic RF switching RF, protection against reverse polarity.
- Net weight (2.2 lb = 1 kg)
- 0.7 kg / 1 lb 8.7 oz (1.542 lb)
- Price in first year of sale
- 58.00 euro
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
