Z477 Western Horse with Clock

Abbotwares; Los Angeles, CA

Données
Forum
Images
Collections

  • Année
  • 1947–1949
  • Catégorie
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 239227

Cliquez sur la vignette du schéma pour le demander en tant que document gratuit.

 Spécifications techniques

  • No. de tubes
  • 5
  • Principe général
  • Superhet with RF-stage; ZF/IF 455 kHz
  • Gammes d'ondes
  • Broadcast only (MW).
  • Tension / type courant
  • AC/DC-set / 110 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Power out
  • 1 W (unknown quality)
  • Material
  • Metal case
  • De Radiomuseum.org
  • Modèle: Z477 Western Horse with Clock - Abbotwares; Los Angeles, CA
  • Shape
  • Design Radio or Novelty / Gadget - fancy or unusual shape.
  • Remarques

  • These horse radios are collectables. Abbotwares used the same basic radio in many different designs of the horses - such as: "Standing Horse", the most often seen version, while the "Rearing Horse & Cowboy" is seldom encountered. Even rare are "Prancing Horse & Cowgirl", "Lady Godiva", "Moose" and "Hula Dancer". All these models have the chassis number Z-477. Please use the right model when uploading collector prices because they differ greatly depending on the model.

    For this model and others, please look up this article and check the models present before creating an other. At the moment we do not distinguish the materials and sizes. This will come later when we can present more pictures. Now we include data in the caption - if well done.

    This model "Western Horse with Swiss Alarm Clock" - see the ad from "The Billboard" Nov. 1947 - has an attached saddle. The horse is 7.5 inch in hight, the radio has 3 inch hight - in total it is 10.5 inch in hight. It is in this case a model size 2. The clock has a diameter of 4 inch.

  • Auteur
  • Modèle crée par Ernst Erb. Voir les propositions de modification pour les contributeurs supplémentaires.
