• Country
• Sweden

• Manufacturer / Brand
• AGA and Aga-Baltic Radio AB; Sweden

• Year
• 1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 190487

• • alternative name: AGA-Baltic Radio AB; Stockholm

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: 3240 - AGA and Aga-Baltic Radio AB;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 260 x 200 x 120 mm / 10.2 x 7.9 x 4.7 inch

• Price in first year of sale
• 345.00 SEK

• Author
• Model page created by Aglef Tröger. See "Data change" for further contributors.

• Other Models

• Here you find 309 models, 228 with images and 209 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from AGA and Aga-Baltic Radio AB; Sweden
