• Country
• United States of America (USA)

• Manufacturer / Brand
• Air King Products Co.; Brooklyn (NY)

• Year
• 1950 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 251571

• Number of Tubes
• 5

• Valves / Tubes
• 1280 12SQ7GT 50L6GT 50L6GT 35Z5

• Wave bands
• - without

• Details
• Wire Recorder (or -Player)

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch

• Power out
• 5 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Wire Recorder A 750/1 [Phono] - Air King Products Co.;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 360 x 240 x 360 mm / 14.2 x 9.4 x 14.2 inch

• Notes

• Wire recorder with disk player only 78 rpm. The collector reel is the turntable for disk player.

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)

• Mentioned in
• -- Collector info (Sammler)

• Author
• Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.

• Other Models

• Here you find 293 models, 145 with images and 240 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Air King Products Co.; Brooklyn (NY)
