Nr. 80108
Ansorge, Kurt, Linz/Donau
- Country
- Austria
- Manufacturer / Brand
- Ansorge, Kurt, Linz/Donau
- Year
- 1929 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 310165
- Number of Tubes
- 5
- Valves / Tubes
- E442S E438 E438 unknown_Tube RGN354
- Main principle
- TRF with regeneration
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 150; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: Nr. 80108 - Ansorge, Kurt, Linz/Donau
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 580 x 240 x 250 mm / 22.8 x 9.4 x 9.8 inch
- Notes
-
Ansorge 2-Kreis Empfänger für Anschluss an das Wechselstromnetz.
Die Nr. 80108 ist wahrscheinlich eine Seriennummer. Die Type ist nicht bekannt.
- Net weight (2.2 lb = 1 kg)
- 9.4 kg / 20 lb 11.3 oz (20.705 lb)
- Author
- Model page created by Franz Buchsbaum. See "Data change" for further contributors.
