Luminor E65
Ariane; Paris
- Country
- France
- Manufacturer / Brand
- Ariane; Paris
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 200208
- Number of Tubes
- 6
- Valves / Tubes
- AK2 AF3 AB2 AF7 AL2 AZ1 Inductance_coil Inductance_coil
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Visual Tuning Indicator pre Eye
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Luminor E65 - Ariane; Paris
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 370 x 505 x 255 mm / 14.6 x 19.9 x 10 inch
- Notes
-
3 gammes d'ondes: OC 18 - 51 m, PO 200 - 560 m, GO 1000 - 2000 m. Bobinages sous vide en ampoule de verre. Cadran lumineux, indicateurs lumineux multicolores, indicateur de contrôle visuel.
Successeur du Luminor 60.
Ébénisterie grand luxe en palissandre et métal chromé.
- Net weight (2.2 lb = 1 kg)
- 14.8 kg / 32 lb 9.6 oz (32.599 lb)
- Price in first year of sale
- 1,990.00 FRF
- Mentioned in
- -- Original prospect or advert (Gamme 1936)
- Literature/Schematics (1)
- Le grand livre de la TSF (Doctsf Ref 9733)
- Author
- Model page created by Bekir Yurdakul. See "Data change" for further contributors.
