• Country
• Netherlands

• Manufacturer / Brand
• Aristona; Eindhoven

• Year
• 1964 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 304104

• • Brand: Aristona

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors
• AC107 AC107 OC75 OC75 OC75 OC75 OC44 OC44 OC74 OC74 OC74 OC74 OC79 OA70 OA70

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 245 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 1.6 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: SA6147A - Aristona; Eindhoven

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 360 x 290 x 160 mm / 14.2 x 11.4 x 6.3 inch

• Notes

• Stereo Tonbandgerät mit 4 Spuren und 2 Geschwindigkeiten (4,75 und 9,5 cm/s).

  Lautsprecher 1: permanent magnetisch, Durchmesser 10 cm.
  Lautsprecher 2: permanent magnetisch, Oval 10 x 15 cm.

  Ausgangsleistung: 2 x 800 mW.

  Siehe auch Modelle Philips EL3547A und Siera SA6147A.

• Mentioned in
• - - Manufacturers Literature ("Aristona - collectie 1966 - technische gegevens")

• Author
• Model page created by Gidi Verheijen. See "Data change" for further contributors.
