SA6223T
Aristona; Eindhoven
- Country
- Netherlands
- Manufacturer / Brand
- Aristona; Eindhoven
- Year
- 1964 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 303949
-
- Brand: Aristona
Aristona All Transistor
nur das Allernötigste
C links oben Veränderung
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: SA6223T - Aristona; Eindhoven
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 205 x 155 x 60 mm / 8.1 x 6.1 x 2.4 inch
- Notes
-
Kleines Transistorgerät mit minimalistischer Skala, in Farben rot, blau, anthrazit oder grau.
Baugleich mit SBR P31 - Nur der Aufdruck auf dem Metall-Einsatz der leicht demontierbaren Skala ist anders.
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Bruce Cohen. See "Data change" for further contributors.
