• Country
• Netherlands

• Manufacturer / Brand
• Aristona; Eindhoven

• Year
• 1964 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 304030

• • Brand: Aristona

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• AF102 AF115 AF116 AC125 OC75 OC75 AC128 AC128 E25C5 AA119 BA102 OA90

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Dry Batteries

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch

• Power out
• 1 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: SA7243T - Aristona; Eindhoven

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 320 x 190 x 95 mm / 12.6 x 7.5 x 3.7 inch

• Notes

• Dioden: 4 x AA119, 2 x OA90, 1x BA102.

  Siehe auch Modelle Siera SA7243T und Radiola RA7243T.

  Obwohl das Modell 10 Transistoren enthält, werden in der Beschreibung nur 8 Transistoren spezifiziert.

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Gidi Verheijen. See "Data change" for further contributors.

• Other Models

• Here you find 209 models, 174 with images and 85 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Aristona; Eindhoven
