32R98 Ch= 1.69801 and 1.69802
Arvin, brand of Noblitt-Sparks Industries
- País
- Estados Unidos
- Fabricante / Marca
- Arvin, brand of Noblitt-Sparks Industries
- Año
- 1962 ?
- Categoría
- Radio - o Sintonizador pasado WW2
- Radiomuseum.org ID
- 228445
Haga clic en la miniatura esquemática para solicitarlo como documento gratuito.
- Numero de valvulas
- 15
- Válvulas
- 6C9_Twin-Tetrode 12BA6 12BE6 12BA6 19HS6 6FG6 12AV6 12AX7 12AX7 12AV6 32ET5 32ET5 12AV6 32ET5 32ET5
- Principio principal
- Superheterodino en general
- Gama de ondas
- OM y FM
- Tensión de funcionamiento
- Red: Corriente alterna (CA, Inglés = AC) / 110-120 Volt
- Altavoz
- 2 Altavoces / Ø 6 inch = 15.2 cm
- Material
- Madera
- de Radiomuseum.org
- Modelo: 32R98 Ch= 1.69801 and 1.69802 - Arvin, brand of Noblitt-Sparks
- Forma
- Sobremesa apaisado (tamaño grande).
- Ancho, altura, profundidad
- 20 x 8.5 x 9 inch / 508 x 216 x 229 mm
- Anotaciones
-
AM/FM, FM Multiplex Stereo table top radio with external speaker. Wood cabinets. Seperate speaker cabinet measures 10 x 8.5 x 9 inches. Actually we seek a schematic for the chassis 1.69801, but we also believe that there are only very minor changes to chassis 1.69802 for which we can show a schematic (SAMS date 8-63, set 647, folder 5).
- Documentación / Esquemas (3)
- Photofact Folder, Howard W. SAMS (Date 8 1963, Set 647 Folder 5)
- Autor
- Modelo creado por Jim Ray. Ver en "Modificar Ficha" los participantes posteriores.
- Otros modelos
-
Donde encontrará 698 modelos, 487 con imágenes y 558 con esquemas.
Ir al listado general de Arvin, brand of Noblitt-Sparks Industries
Contribuciones en el Foro acerca de este modelo: Arvin, brand of: 32R98 Ch= 1.69801 and 1.69802
Hilos: 1 | Mensajes: 3
I'm trying to track down a schematic for an Arvin table top radio from around 19623/63, model 32R98, chassis 1.69801. I have two Photofacts for the same model radio. One is for the 32R98, chassis 1.69802 (Sams 647-5) and the other is 32R98-1, Chassis 1.69803 (Sams 692-6). Niether matches the components in the radio I have. I have contacted Sams and they do not have a Photofact for the 1.69801 chassis.
I'm hoping someone either has the schematic for this chassis or the actual radio to help me determine the value of a burnt resistor (I think) in the radio I have.
I would very much appreciate any information you might have.
JIm
Jim Ray, 19.Dec.12
