• Country
• France

• Manufacturer / Brand
• Atlantic; Paris

• Year
• 1966/1967

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 253354

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• AF126 AF126 AF126 BC109 AC127 AC128 AA119 BA114

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 2 x 4,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10.3 cm = 4.1 inch

• Power out
• 0.15 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: A451 - Atlantic; Paris

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• 2 gammes d'ondes: PO 184 à 577 m, GO 1132 à 2041 m. Clavier à 3 touches. Cadre ferrocapteur fixe. Prise antenne voiture commutée.

• Mentioned in
• -- Original-techn. papers.
