206

Atwater Kent (Brand), C & A Odlin & Co. Ltd; Wellington

Data
Forum
Pictures
Collections

  • Year
  • 1935 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 354805

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 472 kHz
  • Wave bands
  • Broadcast, Short Wave(s) and Police.
  • Power type and voltage
  • Alternating Current supply (AC) / 50Hz, 230 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 206 - Atwater Kent Brand, C & A
  • Shape
  • Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
  • Dimensions (WHD)
  • 14 x 18 x 9.5 inch / 356 x 457 x 241 mm
  • Notes

  • Atwater Kent Model 206

    KNOWN as the inveterate traveller', for it brings you programmes from far-distant lands, clearly and with fidelity. All-Wave for AII-World Reception. Also Console Model 376c with equal performance.

    Believed to be the export version of US Model 206 Type 2 with the above tubes (valves) as the NZ advertising predates later versions. Type 1 schematic included.

    Made in the USA and distributed in New Zealand by C & A Odlin & Co Ltd.

  • Mentioned in
  • -- Original prospect or advert (Press 29 March 1935 Page 13)
  • Author
  • Model page created by Brian Stevens. See "Data change" for further contributors.
