Cadre Radio-Diapason Système Cazes-Berrens
Berrens, J.-H. (JHB, J.H.B.), Abelé; Paris
- Country
- France
- Manufacturer / Brand
- Berrens, J.-H. (JHB, J.H.B.), Abelé; Paris
- Year
- 1926
- Category
- Antenna (Aerial) or Coupler
- Radiomuseum.org ID
- 322906
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- No Power needed
- Loudspeaker
- - - No sound reproduction output.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Cadre Radio-Diapason Système Cazes-Berrens - Berrens, J.-H. JHB, J.H.B.,
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 350 x 750 x 200 mm / 13.8 x 29.5 x 7.9 inch
- Notes
-
Cadre antenne permettant le réglage d'un récepteur à l'aide du cadre et d'une table d'orientation radiogoniométrique.
- Net weight (2.2 lb = 1 kg)
- 3.8 kg / 8 lb 5.9 oz (8.37 lb)
- Mentioned in
- Excelsior, 28.10.1926
- Literature/Schematics (1)
- -- Original prospect or advert
- Author
- Model page created by Marc Couque. See "Data change" for further contributors.
