• Year
  • 1934/1935
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 260647

 Technical Specifications

  • Number of Tubes
  • 6
  • Valves / Tubes
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • AC/DC-set / 110; 220 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Cadet VI - Bonvoisin, L., Mizéry &
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 350 x 200 x 250 mm / 13.8 x 7.9 x 9.8 inch
  • Notes
  • Superhétérodyne à 6 lampes dont 1 valve. Cadran type « avion » demultiplié.

    Alimentation courant continu ou alternatif de 25 à 60 périodes.

    Coffret en ronce de noyer, livré en mallette.

    Prix en mars 1934 (probablement de la saison 33/34). Prix pour 1935 : 1350 Fr.

  • Net weight (2.2 lb = 1 kg)
  • 5.5 kg / 12 lb 1.8 oz (12.115 lb)
  • Price in first year of sale
  • 1,425.00 FRF
  • Mentioned in
  • -- Original prospect or advert (Depliant Bonvoisin 'L'Art et Technique' 1934/35)
  • Literature/Schematics (1)
  • Radio & Phono Materiel, No. 95, Mars 1934
  • Author
  • Model page created by Manfred Rathgeb. See "Data change" for further contributors.
