Autoflex Compact 6/12 V 226

Bouyer, Paul (Harmonic Radio); Montauban, Paris

Data
Forum
Pictures
Collections

  • Year
  • 1962–1968
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 320424

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 5
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 10 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Autoflex Compact 6/12 V 226 - Bouyer, Paul Harmonic Radio;
  • Shape
  • Chassis only or for «building in»
  • Notes

  • Branchement :

    • Haut-parleur, impédance 4, 8 ou 15 ohms
    • Microphone
    • Pick-up
    • Batterie

    Puissance de sortie : 10 watts sur 12 volts, 8 watts sur 6 volts.

  • Price in first year of sale
  • 450.00 FRF
  • Mentioned in
  • - - Manufacturers Literature (Tarif D25, 2/63 (FR) + 2/68 (DE))
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Literature/Schematics (2)
  • Catalogue Comptoir TSF Sud-Est 1963
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
