CSV510

• Country
• Germany

• Manufacturer / Brand
• Braun; Frankfurt

• Year
• 1971–1973

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 28378

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 36

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 100 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: CSV510 - Braun; Frankfurt

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 400 x 110 x 320 mm / 15.7 x 4.3 x 12.6 inch

• Notes

• Braun Stereo-NF-Verstärker Modell CSV-510.
  2x 50 Watt Sinus
  2x 70 Watt Musik
  15 - 35000Hz, THD 0,25%

  36x Si-Transistoren, 5x Si-Dioden, 1x Si-, 1x Se-Brückengleichrichter

  Preis in Dänemark 1973: 2995,-- KR (HiFi Arbogen 1973 (Danmark) - page 67)

• Net weight (2.2 lb = 1 kg)
• 12.5 kg / 27 lb 8.5 oz (27.533 lb)

• Price in first year of sale
• 1,448.00 DM

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1971/1972
