• Country
• Germany

• Manufacturer / Brand
• Braun; Frankfurt

• Year
• 1973/1974

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 129647

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: HiFi-Lautsprechereinheit L 550/1 - Braun; Frankfurt

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 280 x 650 x 125 mm / 11 x 25.6 x 4.9 inch

• Notes
• Ein Tiefton-System 21 cm, ein Hochton-System 2,5 cm, Übertragungsbereich 30-25000 Hz, Nennbelastung 35 Watt, Impedanz 4 Ohm, Weiche 1800 Hz, auch aufhängbar.

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• Price in first year of sale
• 385.00 DM

• Mentioned in
• -- Original-techn. papers. (Weiler Angebot 1973/74)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
