Musiktruhe 222UKW MT (MT222UKW) Ch= Ph222UK

• Country
• Germany

• Manufacturer / Brand
• Braun; Frankfurt

• Year
• 1953/1954

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 19441

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• EF80 EC92 ECH81 EF85 EM11 EABC80 EL41

• Number of Transistors

• Semiconductors
• B250C85

• Main principle
• Superheterodyne (common); ZF/IF 472/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125: 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Musiktruhe 222UKW MT Ch= Ph222UK - Braun; Frankfurt

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 510 x 780 x 370 mm / 20.1 x 30.7 x 14.6 inch

• Notes

• Phono-Chassis = 777W

• Net weight (2.2 lb = 1 kg)
• 23 kg / 50 lb 10.6 oz (50.661 lb)

• Price in first year of sale
• 478.00 DM

• External source of data
• Erb

• Source of data
• Kat.d.Rundf.GrossH.1953/54

• Literature/Schematics (1)
• -- Schematic

• Other Models

• Here you find 1061 models, 931 with images and 652 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Braun; Frankfurt
