Steuergerät Synthesizer, Studio System RS1
Braun; Frankfurt
- Country
- Germany
- Manufacturer / Brand
- Braun; Frankfurt
- Year
- 1978–1980
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 79893
STS Archív.
STS Archív.
STS Archív.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 130 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Steuergerät Synthesizer, Studio System RS1 - Braun; Frankfurt
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 605 x 65 x 330 mm / 23.8 x 2.6 x 13 inch
- Notes
-
HiFi-AM/FM-Receiver mit 2 x 65 Watt Sinus an 4 Ohm. 2× MW und 6× FM-Stationstasten, Anzeige über LED Kette.
Gehäusefarbe Schwarz oder Grau.Das Modell verfügt über eine Lithium Stützbatterie mit einer geschätzten Lebensdauer von mind.10 Jahren. Bei nicht mehr funktionsfähiger Pufferung durch die Lithium-Batterie verlieren die Stationsspeicher ihre Funktion.
- Net weight (2.2 lb = 1 kg)
- 9.6 kg / 21 lb 2.3 oz (21.145 lb)
- Price in first year of sale
- 1,798.00 DM
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Peter Böhm. See "Data change" for further contributors.
