• Country
• France

• Manufacturer / Brand
• Broadcast Radio, Levallois (Seine)

• Year
• 1959 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 131031

• Number of Transistors
• 7

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage and/or dry batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: 627 - Broadcast Radio, Levallois

• Dimensions (WHD)
• 300 x 190 x 115 mm / 11.8 x 7.5 x 4.5 inch

• Notes
• 1 Transistor OC44 + 6 transistors Thomson non encore identifiés.

• Net weight (2.2 lb = 1 kg)
• 2.2 kg / 4 lb 13.5 oz (4.846 lb)

• Author
• Model page created by Laurent Farnieras. See "Data change" for further contributors.

• Other Models

• Here you find 4 models, 4 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
