Counter Checker Type C
Burton-Rogers Company; Boston MA
- País
- Estados Unidos
- Fabricante / Marca
- Burton-Rogers Company; Boston MA
- Año
- 1930/1931
- Categoría
- Aparato de medida y servicio (Equipo de laboratorio).
- Radiomuseum.org ID
- 206440
- Gama de ondas
- - no hay
- Tensión de funcionamiento
- Red: Corriente alterna (CA, Inglés = AC) / 110 Volt
- Altavoz
- - - No hay salida de sonido.
- Material
- Bakelita
- de Radiomuseum.org
- Modelo: Counter Checker Type C - Burton-Rogers Company; Boston
- Forma
- Sobremesa, caja, normalmente con tapa (panel no inclinado).
- Ancho, altura, profundidad
- 7 x 2.5 x 5.5 inch / 178 x 64 x 140 mm
- Anotaciones
- The Burton-Rogers Tube Counter Checker Type C is featured in the catalog 1930-1931 of "The James Bailey Company, Portland, Maine, together with other Burton-Rogers radio products like Tube Checker Type C, 180 Test Oscillator, Set Analyzer, Junior Set Analyzer and the "Portable combination Analyzer and Tube Checker. This Burton-Rogers Counter Checker Type C is "The same as Type B in addition Type C has two voltage scales 0-20, 0-400 so that such parts may be tested as Band C Batteries, B eliminators, Audio Transformers, Audio Choke Coils, Resistors, RF Coils and RF chioes." Has also the range 0-20 MA. Dealer's net price is $ 22.80. Special model 25 cycles $ 23.80.
- Peso neto
- 3.5 lb (3 lb 8 oz) / 1.589 kg
- Autor
- Modelo creado por Ernst Erb. Ver en "Modificar Ficha" los participantes posteriores.
