Multimeter 517 A
Centrad; Annecy
- Country
- France
- Manufacturer / Brand
- Centrad; Annecy
- Year
- 1966
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 121392
Centrad 517A
FR "Television" No 163 June 1966
717A en mallette
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Dry Batteries
- Loudspeaker
- - - No sound reproduction output.
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: Multimeter 517 A - Centrad; Annecy
- Dimensions (WHD)
- 85 x 127 x 30 mm / 3.3 x 5 x 1.2 inch
- Notes
- Multimeter, 7 DC voltage ranges up to 1.000 V; 6 AC voltage ranges up to 2.500 V; ampere up to 5 A; 6 ranges up to 100 Mohm, 4 ranges up to 150 µF.
- Mentioned in
- FR "Television" No 163 June 1966
- Author
- Model page created by a member from A. See "Data change" for further contributors.
