• Country
• France

• Manufacturer / Brand
• Central-Radio; Paris

• Year
• 1948

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 143348

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• 6M7 6E8 6M7 6Q7 6AF7 6N7 6V6 6J7 6V6 6V6 5U4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Bicanal 115 - Central-Radio; Paris

• Notes
• 3 OC dont 2 bandes étalées, push-pull de 6V6.

• Literature/Schematics (1)
• Radio Constructeur et Dépanneur 1948

• Author
• Model page created by Raynal Aufils. See "Data change" for further contributors.
