• Country
• France

• Manufacturer / Brand
• Central-Radio; Paris

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 139516

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECC85 EF89 ECH81 EF89 EM85 EABC80 EL84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 115; 130; 220; 240 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: RCR 859 HF AM/FM - Central-Radio; Paris

• Shape
• Tablemodel with Push Buttons.

• Notes
• Clavier 6 touches, cadre à air rotatif, 2 H.P, ébénisterie grand luxe, noyer, palissandre ou acajou.

• Literature/Schematics (1)
• Radio Constructeur et Dépanneur 1958

• Author
• Model page created by Raynal Aufils. See "Data change" for further contributors.
