• Country
• France

• Manufacturer / Brand
• Central-Radio; Paris

• Year
• 1952

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 122502

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 1T4 1R5 1T4 1S5 3S4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Line / Batteries (any type) / AC 110 ; 220 ; Batt. 9 & 90 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Vox Camping 52 - Central-Radio; Paris

• Notes
• Récepteur portatif. Alimentation secteur ou piles. Redressement diode Y15. Bois gainé cuir. H.P. elliptique 10 X 12cm. Cadre.

• Literature/Schematics (1)
• Radio Constructeur et Dépanneur de 1952

• Author
• Model page created by Raynal Aufils. See "Data change" for further contributors.
